Water Suction Discharge Hose

Water Suction Discharge Hose

These hoses are optimized for industrial pumping, dewatering, and water transfer. Built to handle suction and discharge applications with strength and flexibility. Offered in bulk lengths or assembled configurations.

Construction:

  • Tube is black Natural rubber blend compound
  • Cover is black Natural rubber-abrasion, weather,and ozone resistant
  • Reinforcement is multiple layers of high tensile nylon cord with helix wire

Operating Temperature: -20°F/+180°F(-29°C/+82°C)

Safety Factor: 3:1

Application:

  • Delivery and suction application
  • Waste water,sewage,mud,etc
Request a quote

Product Specifications

Part Number Title Color Hose I.D. Hose O.D. Tubing Gauge Working Pressure Burst Pressure Min. Band Radius Max Length Weight Material
(inch) (mm) (inch) (mm) (inch) (psi) (bar) (psi) (bar) (psi) (bar) (ft) (lb/ft)
LH-SW150-032 1-1/4" 150 PSI Water Suction Discharge Hose Black 1.25 in 32 mm 1.77 in 45 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-305 12" 150 PSI Water Suction Discharge Hose Black 12 in 305 mm 12.8 in 325 mm - 150 10 450 30 - - 50 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-254 10" 150 PSI Water Suction Discharge Hose Black 10 in 254 mm 10.81 in 275 mm - 150 10 450 30 - - 50 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-203 8" 150 PSI Water Suction Discharge Hose Black 8 in 203 mm 8.78 in 223 mm - 150 10 450 30 - - 50 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-152 6" 150 PSI Water Suction Discharge Hose Black 6 in 152 mm 6.73 in 171 mm - 150 10 450 30 - - 100 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-127 5" 150 PSI Water Suction Discharge Hose Black 5 in 127 mm 5.71 in 145 mm - 150 10 450 30 - - 100 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-102 4" 150 PSI Water Suction Discharge Hose Black 4 in 102 mm 4.72 in 120 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-090 3-1/2" 150 PSI Water Suction Discharge Hose Black 3.5 in 90 mm 4.25 in 108 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-080 3-3/16" 150 PSI Water Suction Discharge Hose Black 3.19 in 80 mm 3.86 in 98 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-076 3" 150 PSI Water Suction Discharge Hose Black 3 in 76 mm 3.7 in 94 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-063 2-1/2" 150 PSI Water Suction Discharge Hose Black 2.5 in 63 mm 3.15 in 80 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-051 2" 150 PSI Water Suction Discharge Hose Black 2 in 51 mm 2.56 in 65 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-045 1-3/4" 150 PSI Water Suction Discharge Hose Black 1.75 in 45 mm 2.32 in 59 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-038 1-1/2" 150 PSI Water Suction Discharge Hose Black 1.5 in 38 mm 2.01 in 51 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-035 1-3/8" 150 PSI Water Suction Discharge Hose Black 1.38 in 35 mm 1.89 in 48 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-SW150-025 1" 150 PSI Water Suction Discharge Hose Black 1 in 25 mm 1.5 in 38 mm - 150 10 450 30 - - 200 ft - High tensile cord/helix steel wire/rubber compound
LH-DW150-032 1-1/4" 300 PSI Water Discharge Hose Black 1.25 in 32 mm 1.69 in 43 mm - 300 20 900 60 - - 200 ft - synthetic rubber
LH-DW150-038 1-1/2" 300 PSI Water Discharge Hose Black 1.5 in 38 mm 1.93 in 49 mm - 300 20 900 60 - - 200 ft - synthetic rubber
LH-DW150-045 1-3/4" 300 PSI Water Discharge Hose Black 1.75 in 45 mm 2.32 in 59 mm - 300 20 900 60 - - 200 ft - synthetic rubber
LH-DW150-051 2" 300 PSI Water Discharge Hose Black 2 in 51 mm 2.56 in 65 mm - 300 20 900 60 - - 200 ft - synthetic rubber
LH-DW150-063 2-1/2" 300 PSI Water Discharge Hose Black 2.5 in 63 mm 3.11 in 79 mm - 300 20 900 60 - - 200 ft - synthetic rubber
LH-DW150-076 3" 300 PSI Water Discharge Hose Black 3 in 76 mm 3.62 in 92 mm - 300 20 900 60 - - 200 ft - synthetic rubber
LH-DW150-102 4" 300 PSI Water Discharge Hose Black 4 in 102 mm 4.72 in 120 mm - 300 20 900 60 - - 200 ft - synthetic rubber
LH-DW150-127 5" 300 PSI Water Discharge Hose Black 5 in 127 mm 5.51 in 140 mm - 300 20 900 60 - - 100 ft - synthetic rubber
LH-DW150-152 6" 300 PSI Water Discharge Hose Black 6 in 152 mm 6.5 in 165 mm - 300 20 900 30 - - 100 ft - synthetic rubber
LH-DW150-203 8" 300 PSI Water Discharge Hose Black 8 in 203 mm 8.54 in 217 mm - 300 20 900 60 - - 50 ft - synthetic rubber
LH-DW150-254 10" 300 PSI Water Discharge Hose Black 10 in 254 mm 11.06 in 281 mm - 300 20 900 60 - - 50 ft - synthetic rubber
LH-DW150-304 12" 300 PSI Water Discharge Hose Black 12 in 304 mm 13.11 in 333 mm - 300 20 900 60 - - 50 ft - synthetic rubber
